Feature
＊ Easy Installation Compact Light Design weight.
＊ Mounting 20L & 80L
＊ Dispensing high Viscosity epoxy without loss and bubble.
＊ Self Developed Valve can improving accuracy and productivity.
＊ Together with Interface Auto Line can crossing
＊ Easy Exhaust volume adjustable touch screen.
＊ Working Together Auto Line
＊ Resin/Hardener Selecting, Intermit Exhaust, Prevention Hardener
Spec
＊ Dimension : 100(w) x 900(L) x 1465(H)
＊ Weight : 360kg
＊ Can Volume : 20L & 80L(Resin/ Hardener)
＊ Mixing Method : Static Mixer
＊ Pumping Method : Gear Pump
＊ Mixing Ratio : 100:10 ~ 100:100
＊ Viscosity : 1cps ~ 1,000,000cps
＊ Exhaust Volume : Max 2,000cc/min
[ Discharging Volume is changed by Viscosity and Gravity]
